| DVR / NVR / XVR Specification | |
| Auxiliary Interface | SATA : SATA Capacity : Up to 6 TB capacity for each disk Alarm In/Out n: N/A USB Interface : Rear panel: 2 × USB 2.0 |
| Component Environment | Working Temperature : -10 °C to 55 °C (14 °F to 131 °F) Working Humidity : 10% to 90% Dimensions (W × D × H) : 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) Weights (Without HDD) : ≤ 0.8 kg (1.8 lb) |
| Network | Remote Connections : 32 Network Protocols : TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS Network Interface : 1, RJ45 10M/100M self-adaptive Ethernet interface |
| Recording | Video Compression : H.264+/H.264 Encoding Resolution : When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF, When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF Frame Rate : Main stream: When 1080p Lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N), When 1080p Lite mode enabled: : 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N), Sub-stream: : 2CIF@6fps; CIF/QVGA/QCIF@ 25fps (P)/30fps (N) Video Bit Rate : 32 Kbps to 4 Mbps Dual Stream : Support Stream Type : Video, Video & Audio Audio Compression : G.711u Audio Bit Rate : 64 Kbps |
| Video and Audio | IP Video Input : Up to 4-ch Up to 960p resolution Support H.264+/H.264 IP cameras Analog Video Input : 4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection Turbo HD Input : 1080p25, 1080p30, 720p25, 720p30 AHD Input : 1080p25, 1080p30, 720p25, 720p30 HDCVI Input : 1080p25, 1080p30, 720p25, 720p30 CVBS Input : Support Audio Input : 1-ch, RCA (2.0 Vp-p, 1 KΩ) Audio Output : 1-ch, RCA (Linear, 1 KΩ) Two-Way Audio : Reuse the first audio input Synchronous Playback : 4-ch VGA/HDMI Output : 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Power | Power Supply : 12 VDC Consumption (Without HDD) : ≤ 8 W |
| Warranty Information | |
| Warranty | 01 year warranty |
