Name: GIGABYTE Z790 D DDR5 ATX Motherboard
Brand: GIGABYTE
Price: 28500.00 BDT
Availability: OutOfStock
Rating: 5 (1 reviews)

-2 % In Stock

GIGABYTE Z790 D DDR5 ATX Motherboard

Stock: In Stock
Brand: GIGABYTE
Model: Z790 D

Based on 1 reviews. - Write a review

28,500৳

29,000৳

Ex Tax: 28,500৳

Qty

Buy Now

Buy Now Add to Compare

Add to Wish List Compare this Product

Key Features

- Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
- Supported RAM: 4x DDR5, Max 192GB 7600(O.C.)
- Graphics Output: 1x HDMI, 1x DisplayPort
- Features: Realtek 2.5GbE LAN chip

View More Info

Specification

Physical Specification
Slots	4 x DDR5 DIMM sockets
Supported Memory	14th and 13th Generation Intel Core i9/i7 Pocessors: - Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600 / 5400 / 5200/ 4800/4400 MT/s memory modules 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors: - Support for DDR5 4800/4400 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
Maximum Memory	up to 192 GB (48 GB single DIMM capacity) of system memory
Basic Information
Supported CPU	LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core, Pentium Gold and Celeron Processors (Go to GIGABYTE's website for the latest CPU support list.) L3 cache varies with CPU
Chipset	Intel Z790 Express Chipset
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Audio	Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out
Type	DDR5
Expansion Slots
PCI	CPU: - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4) - 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3)
Graphics
Graphics	Integrated Graphics Processor-Intel® HD Graphics support: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support for native HDMI 2.1 TMDS compatible ports. - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.)
Connector & Ports
HDMI	1 x HDMI port
RAID	RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Display Port (s)	1 x DisplayPort
USB (s)	Chipset: - 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support - 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel - 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) - 2 x USB 2.0/1.1 ports on the back panel Chipset+USB 2.0 Hub: - 4 x USB 2.0/1.1 ports, available through the internal USB headers
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Supported Storage	CPU: - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: - 1 x M.2 connectors (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) - 1 x M.2 connectors (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2M_SB) - 4 x SATA 6Gb/s connectors
Audio	3 x audio jacks
Internal I/O Ports	Internal I/O Connectors 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB Type-C header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt add-in card connectors 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x USB Type-C port, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) 4 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x HDMI port 1 x DisplayPort 1 x RJ-45 port 3 x audio jacks
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
Others Information
Bundled Software	Norton Internet Security (OEM version) cFosSpeed
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Warranty Information
Warranty	3 years

Description

GIGABYTE Z790 D DDR5 ATX Motherboard

The GIGABYTE Z790 D DDR5 ATX Motherboard is a high-performance and future-ready platform designed to support the latest Intel 12th, 13th, and 14th Generation processors. Featuring the Intel Z790 Express chipset and an LGA1700 socket, this motherboard delivers exceptional computing power, making it suitable for gamers, content creators, and professional users who demand speed, stability, and reliability. It is compatible with a wide range of Intel CPUs including Core i9, i7, i5, i3, Pentium Gold, and Celeron processors, offering versatile options for both high-end and cost-effective PC builds. The Z790 D DDR5 motherboard supports DDR5 memory across four DIMM slots, allowing up to 192GB of system memory. With support for high memory speeds, including up to 7600 MHz (OC) for 14th and 13th Generation Core i9/i7 processors, users can experience faster load times, improved multitasking, and enhanced overall system performance. The motherboard also supports XMP profiles and ECC memory in non-ECC mode, ensuring maximum flexibility and compatibility. For graphics, it provides integrated Intel HD Graphics with an HDMI 2.1 port supporting 4K at 60Hz and a DisplayPort supporting 4K at 60Hz. Multi-GPU support is available for users planning to install dedicated graphics cards. Storage options are comprehensive, including three M.2 slots supporting PCIe 4.0/5.0 NVMe SSDs and four SATA 6Gb/s connectors with RAID 0, 1, 5, and 10 support for both NVMe and SATA drives. Connectivity is robust with a Realtek 2.5GbE LAN port, multiple USB 3.2 and USB 2.0 ports, and USB Type-C support. Audio is powered by Realtek High Definition Audio with 7.1-channel output. Special features include GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, and Smart Backup. With a durable ATX form factor and a 3-year warranty, the GIGABYTE Z790 D DDR5 ATX Motherboard is a reliable foundation for high-performance Intel systems

Features Of GIGABYTE Z790 D DDR5 ATX Motherboard

Supported CPU: LGA1700 socket compatible with 14th, 13th, and 12th Generation Intel® Core™, Pentium Gold, and Celeron processors for versatile and high-performance builds.
High-Speed DDR5 Memory: 4 DIMM slots supporting up to 192GB of DDR5 RAM with speeds up to 7600 MHz (O.C.) and dual-channel architecture for faster multitasking and efficient performance.
Advanced Graphics Support: Integrated Intel HD Graphics with 1x HDMI 2.1 port (4K@60Hz) and 1x DisplayPort (4K@60Hz), plus multi-GPU support for enhanced gaming and professional workloads.
Extensive Expansion Slots: Includes PCIe 5.0 x16, PCIe 4.0 x16, PCIe 3.0 x16, and two PCIe 3.0 x1 slots, allowing flexible installation of graphics cards, NVMe SSDs, and additional peripherals.
High-Speed Networking: Realtek 2.5GbE LAN chip ensures stable, fast, and low-latency wired internet connectivity for gaming, streaming, and large file transfers.
Comprehensive USB Connectivity: Multiple USB 3.2 Gen2/Gen1 Type-A and Type-C ports, along with USB 2.0 headers, for seamless connection of peripherals, external drives, and high-speed devices.
Premium Audio & Special Features: Realtek HD Audio with up to 7.1-channel output, S/PDIF support, GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, and Smart Backup for superior sound, system control, and easy BIOS updates.
