Name: GIGABYTE X870E AORUS PRO ICE DDR5 AM5 ATX Motherboard
Brand: GIGABYTE
Price: 55000.00 BDT
Availability: OutOfStock
Rating: 5 (1 reviews)

GIGABYTE X870E AORUS PRO ICE DDR5 AM5 ATX Motherboard

-7 % In Stock

GIGABYTE X870E AORUS PRO ICE DDR5 AM5 ATX Motherboard

Stock: In Stock
Brand: GIGABYTE
Model: X870E AORUS PRO ICE

Based on 1 reviews. - Write a review

55,000৳

59,130৳

Ex Tax: 55,000৳

Qty

Buy Now

Buy Now Add to Compare

Add to Wish List Compare this Product

Key Features

- Supported CPU: Ryzen 9000 / 8000/ 7000 Series Processors for Socket AM5
- Supported RAM: 4x DDR5, Max 256GB
- Graphics Output: 2 x USB4 (Type-C) , 1 x HDMI, 1x HDMI (front)
- Features: Realtek 2.5GbE LAN & Qualcomm Wi-Fi 7 QCNCM865

View More Info

Specification

Physical Specification
Slots	4 DIMMs
Supported Memory	Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
Basic Information
Supported CPU	AMD Socket AM5, support for: AMD Ryzen 9000, 8000, 7000 Series Processors
Chipset	AMD X870
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Audio	Realtek ALC1220 CODEC * The back panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out
Type	DDR5
Others	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Expansion Slots
PCI	1x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x16 mode * The M2B_CPU and M2C_CPU connectors share bandwidth with the PCIEX16 slot. When the M2B_CPU orM2C_CPU connector is populated, the PCIEX16 slot operates at up to x8 mode. AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode (The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.) Chipset: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4_1) - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4_2)
Graphics
Graphics	Integrated Graphics Processor with AMD Radeon Graphics support: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. * Support for native HDMI 2.1 TMDS compatible ports. - 1 x Front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz * Support for HDMI 1.4 version (Graphics specifications may vary depending on CPU support.)
Connector & Ports
HDMI	1 x HDMI port
RAID	RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices * RAID 5 is only available on AMD Ryzen™ 9000 Series Processors. RAID 0, RAID 1, and RAID 10 support for SATA storage devices
USB (s)	CPU+ASMedia USB4 controller: - 2 x USB4 USB Type-C ports on the back panel CPU: - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel - 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) - 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless Communication module	Qualcomm Wi-Fi 7 QCNCM865 - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11be 320MHz wireless standard (Actual data rate may vary depending on environment and equipment.) * Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10.) ** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations.
Supported Storage	1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs: AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs * The M2B_CPU and M2C_CPU connectors will become unavailable when using the AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 Processors. 1 x M.2 connector (M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
Audio	Realtek ALC1220 CODEC * The back panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out
Internal I/O Ports	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 4 x system fan headers 2 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 4 x SATA 6Gb/s connectors 4 x M.2 Socket 3 connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support 2 x USB 3.2 Gen 1 headers 2 x USB 2.0/1.1 headers 1 x noise detection header 1 x HDMI port (Note) 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI2.0/GC-TPM2.0 SPI V2 module only) 1 x power button 1 x reset button 2 x temperature sensor headers 1 x reset jumper 1 x Clear CMOS jumper Back Panel Connectors 1 x Q-Flash Plus button 2 x USB 2.0/1.1 ports 1 x HDMI port (Note) 4 x USB 3.2 Gen 1 ports 2 x USB4® USB Type-C® port (DisplayPort (Note)) 3 x USB 3.2 Gen 2 Type-A ports (red) 1 x RJ-45 port 2 x antenna connectors (2T2R) 1 x optical S/PDIF Out connector 2 x audio jacks
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI2.0/GC-TPM2.0 SPI V2 module only)
Others Information
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Warranty Information
Warranty	3 Years

Description

GIGABYTE X870E AORUS PRO ICE DDR5 AM5 ATX Motherboard

The GIGABYTE X870E AORUS PRO ICE DDR5 AM5 ATX Motherboard is a next-generation powerhouse engineered to deliver elite performance, exceptional stability, and future-ready connectivity for high-end gaming and professional workloads. Built on the advanced AMD X870 chipset and supporting AMD Ryzen 9000, 8000, and 7000 Series processors, this board ensures outstanding processing efficiency and full compatibility with the latest AM5 platform innovations. Featuring four DDR5 DIMM slots, the motherboard supports ultra-high-speed memory up to DDR5 8000(OC), enabling superior bandwidth and lightning-fast multitasking capabilities. With support for AMD EXPO and Intel XMP, users can optimize performance effortlessly through automated overclocking profiles. Storage capabilities are equally impressive, offering four PCIe M.2 slots, including PCIe 5.0 x4 support for unprecedented NVMe SSD speeds. Combined with RAID 0/1/5/10 availability for NVMe storage, users can enjoy exceptional sequential performance and data redundancy options. For expansion needs, the board integrates a PCIe 5.0 x16 graphics slot, ensuring maximum GPU bandwidth for gaming and content creation. Additional PCIe 4.0 and 3.0 slots provide flexibility for add-on cards and future upgrades. Connectivity is future-proof, with dual USB4 Type-C ports, multiple USB 3.2 Gen 2 and Gen 1 ports, and high-speed front-panel USB 3.2 Gen 2x2 support. Networking is delivered through a Realtek 2.5GbE LAN chip and Qualcomm Wi-Fi 7 with Bluetooth 5.3, providing ultra-fast wireless performance and stable network throughput. For audio, the Realtek ALC1220 codec delivers high-definition 7.1-channel sound with S/PDIF out support, ensuring crystal-clear output for gaming and media professionals. Aesthetically, the AORUS PRO ICE features a premium white-themed design with customizable RGB headers, making it ideal for clean, modern PC builds. Combined with Q-Flash Plus, Smart Backup, and GIGABYTE Control Center, the board offers exceptional usability and system management.

Features Of GIGABYTE X870E AORUS PRO ICE DDR5 AM5 ATX Motherboard

Supports AMD Ryzen 7000, 8000 & 9000 Series processors with AM5 socket
Built on AMD X870E chipset for high-performance and future compatibility
ATX form factor (30.5 × 24.4 cm) for full-size build flexibility
4 DDR5 DIMM slots, supporting up to 256 GB of memory
Supports high-speed DDR5 memory up to 8000+ MT/s (OC) with EXPO/XMP
1 × PCIe 5.0 x16 slot for the latest graphics cards
2 additional PCIe slots (via chipset) for expansion cards
Four M.2 slots for ultra-fast NVMe SSDs
SATA storage support: 4 × SATA 6Gb/s ports, with RAID 0,1,5,10 support
Dual USB4 Type-C ports with DisplayPort functionality
Multiple USB 3.2 Gen 2 + Gen 1 ports for connectivity
Realtek 2.5GbE LAN for fast wired networking
Built-in Wi-Fi 7 (Qualcomm) and Bluetooth 5.3 for advanced wireless connectivity
Realtek ALC1220 audio codec with 7.1-channel HD sound and S/PDIF out
Multiple headers for RGB and Addressable Gen 2 lighting
Fan/pump headers for robust cooling options
Thermistor / temperature sensor support for accurate thermal monitoring
Onboard Clear-CMOS and power/reset buttons
TPM 2.0 header for hardware-level security
Q-Flash Plus support for updating BIOS without CPU / memory
GIGABYTE Control Center (GCC) and Smart Backup software for system tuning
3-year warranty for reliability and peace of mind
