Name: Gigabyte Z890 AORUS ELITE WIFI7 LGA 1851 ATX Motherboard
Brand: GIGABYTE
Price: 42000.00 BDT
Availability: OutOfStock
Rating: 5 (1 reviews)

Gigabyte Z890 AORUS ELITE WIFI7 LGA 1851 ATX Motherboard

-1 % In Stock

Gigabyte Z890 AORUS ELITE WIFI7 LGA 1851 ATX Motherboard

Stock: In Stock
Brand: GIGABYTE
Model: Z890 AORUS ELITE WIFI7

Based on 1 reviews. - Write a review

42,000৳

42,500৳

Ex Tax: 42,000৳

Qty

Buy Now

Buy Now Add to Compare

Add to Wish List Compare this Product

Key Features

- Supported CPU: Intel Core Ultra Processors (Series 2)
- Supported RAM: 4x DDR5
- Graphics Output: HDMI, DisplayPort, Thunderbolt 4 (USB4-C)
- Features: 4x M.2, Intel Wi-Fi 7, Bluetooth 5.4

View More Info

Specification

Physical Specification
Slots	4 x DIMM
Supported Memory	Support for DDR5 9200(O.C) / 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules.
Maximum Memory	256GB
Basic Information
Supported CPU	Intel Core Ultra Processors(Series 2)
Chipset	Intel Z890 Chipset
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
Audio	Realtek® ALC1220 CODEC * The back panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out
Type	DDR5
Expansion Slots
PCI	CPU: - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: - 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2)
M.2 Socket	CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB)
Graphics
Graphics	Integrated Graphics Processor-Intel® HD Graphics support: - 1 x Intel® Thunderbolt™ 4 connector (USB4® USB Type-C® port), supporting DisplayPort and Thunderbolt™ video outputs When a Thunderbolt™ monitor is installed, the maximum resolution supported is 5120x2880@60 Hz with 24 bpp (single display output). When a USB4® USB Type-C® monitor is installed, the maximum resolution supported is 3840x2160@240 Hz (single display output). * Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™ devices that can be used is dependent on the number of the PCI Express devices being installed. (Refer to Chapter 2-6, "Back Panel Connectors," for more information.) * Support for DisplayPort 2.1 version and HDCP 2.3 - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz * Support for HDMI 1.4 version - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 2.1 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.)
Connector & Ports
HDMI	1 x HDMI
RAID	RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Display Port (s)	1 x DisplayPort
USB (s)	CPU: - 1 x Intel® Thunderbolt™ 4 (USB Type-C®) ports on the back panel Support up to 40Gbps with Thunderbolt devices Support up to 20Gbps with USB4 devices *Support up to 10Gbps with USB 3.2 devices Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel - 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: - 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless Communication module	MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0) - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.4 - Support for 11be 160MHz wireless standard Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1) - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.4 - Support for 11be 160MHz wireless standard
Supported Storage	- 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB) - 4 x SATA 6Gb/s connectors
Audio	1 x front panel audio header 2 x audio jacks
Internal I/O Ports	1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 4 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x HDMI port (Note) 1 x power button 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper Back Panel Connectors 1 x Intel® Thunderbolt™ 4 connectors (USB Type-C® ports) 2 x USB 3.2 Gen 2 Type-A ports (red) 3 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 2 x antenna connectors (2T2R) 1 x DisplayPort (Note) 1 x RJ-45 port 1 x optical S/PDIF Out connector 2 x audio jacks
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
Others Information
Bundled Software	Norton® Internet Security (OEM version) LAN bandwidth management software
Special Features	Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup
Warranty Information
Warranty	3 Year Warranty

Description

Gigabyte Z890 AORUS ELITE WIFI7 LGA 1851 ATX Motherboard

The Gigabyte Z890 AORUS ELITE WIFI7 LGA 1851 ATX Motherboard is a next-generation performance platform built for gamers, content creators, and power users who demand exceptional speed, stability, and advanced connectivity. Powered by the latest Intel Z890 chipset, it supports Intel Core Ultra Series 2 processors, delivering top-tier processing power for gaming, multitasking, AI workloads, and high-end productivity. With its durable 12+ power stage design and premium thermal solutions, the motherboard ensures consistent and reliable performance even under extreme workloads. For memory, the board includes 4× DDR5 slots supporting blazing-fast speeds up to DDR5 9200(O.C) and a maximum capacity of 256GB, making it ideal for modern performance-intensive applications. The storage configuration is equally impressive, featuring four M.2 slots—including PCIe 5.0 x4 support—ensuring ultra-fast data access and maximum expandability. Additionally, four SATA 6Gb/s connectors provide further flexibility for traditional storage devices. Connectivity is one of the motherboard’s strongest features. It includes Thunderbolt 4 (USB4 Type-C), multiple USB 3.2 Gen 2 and Gen 1 ports, along with high-speed USB Type-C front-panel support. The integrated Wi-Fi 7 and Bluetooth 5.4 modules deliver next-level wireless speed and stability, while the Realtek 2.5GbE LAN ensures fast and reliable wired networking. For display, users get 1× HDMI, 1× DisplayPort, and Thunderbolt display output, enabling support for high-resolution monitors including 4K, 5K, and high-refresh-rate displays. The Realtek ALC1220 audio codec enhances audio clarity, supporting 7.1-channel HD audio with S/PDIF out. Packed with features like Q-Flash Plus, Smart Backup, onboard RGB lighting headers, and GIGABYTE Control Center, the Z890 AORUS ELITE WIFI7 is a future-proof, high-performance motherboard ready for next-gen gaming and productivity builds.

Features Of Gigabyte Z890 AORUS ELITE WIFI7 LGA 1851 ATX Motherboard

Supports Intel Core Ultra Series 2 Processors: Built for the latest LGA 1851 CPUs, ensuring top-tier performance and future-proof processing power.
High-Speed DDR5 Memory Support: Features 4× DDR5 DIMM slots supporting speeds up to DDR5 9200(O.C) with a maximum capacity of 256GB.
Advanced Graphics Output Options: Includes 1× HDMI, 1× DisplayPort, and 1× Intel Thunderbolt 4 Type-C for high-resolution, high-refresh-rate display support.
Ultra-Fast Storage Support: Equipped with 4× M.2 slots including PCIe 5.0 x4 for next-gen SSD speed and faster boot/load performance.
Next-Gen Wireless Connectivity: Integrated Wi-Fi 7 and Bluetooth 5.4 ensure high-speed, low-latency, and stable wireless performance.
Robust Expansion and Connectivity: Offers PCIe 5.0 GPU slot, multiple USB 3.2 Gen 2/Gen 1 ports, USB Type-C, and Realtek 2.5GbE LAN for seamless connectivity.
Premium Audio and Control Features: Includes Realtek ALC1220 audio, Q-Flash Plus, Smart Backup, and RGB headers for advanced customization and superior sound.
