| General | |
| Operating Conditions | -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| Pan/Tilt/Rotation | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Power | 12 VDC ± 25% |
| Power Consumption | Max. 4.2 W |
| Weight | Approx. 348.5 g (0.77 lb.) |
| Camera | |
| Electronic Shutter Speed | Shutter Time: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s Slow Shutter: Max. 16 times |
| Image Sensor | 2 MP CMOS |
| IR Distance | Up to 40 m white light distance for bright night imaging |
| Minimum Illumination | 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light ON |
| Lens | |
| Focal Length | 2.8 mm, 3.6 mm, 6 mm fixed focal lens |
| Lens Type | Fixed Lens |
| Mount Type | M12 |
| Video | |
| Day/Night | 24/7 Color Imaging |
| Frame Rate | TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVBS: PAL/NTSC |
| Resolution | 1920 (H) × 1080 (V) |
| Video Output | Switchable TVI/AHD/CVI/CVBS |
| Physical Specification | |
| Dimensions | Φ 109.98 mm × 98.27 mm (Φ 4.33" × 3.87") |
| Warranty Information | |
| Warranty | 01 year warranty |
