Name: GIGABYTE B760M D2H DDR5 mATX Motherboard
Brand: Gigabyte
Price: 16930.00 BDT
Availability: OutOfStock

GIGABYTE B760M D2H DDR5 mATX Motherboard

In Stock

GIGABYTE B760M D2H DDR5 mATX Motherboard

Stock: In Stock
Brand: Gigabyte
Model: B760M D2H

Based on 0 reviews. - Write a review

16,930৳

Ex Tax: 16,930৳

Qty

Buy Now

Buy Now Add to Compare

Add to Wish List Compare this Product

Key Features

- Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
- Supported RAM: 2x DDR5, Max 96GB 8000(O.C.)
- Graphics Output: 1x HDMI, 1x D-Sub
- Features: 2.5GbE LAN

View More Info

Description
Review

Description

Basic Information
Supported CPU	LGA1700 socket: Support for the 14th 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with the CPU
Chipset	Intel B760 Express Chipset
BIOS	1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor	Micro ATX Form Factor; 24.4cm x 24.4cm
Audio	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out
Expansion Slots
PCI	CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
Memory
Type	DDR5
Slots	2
Supported Memory	Support for DDR5 8000(O.C.) /7800(O.C.) /7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules
Maximum Memory	up to 96 GB (48 GB single DIMM capacity) of system memory
Graphics
Graphics	Integrated Graphics Processor-Intel® HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for the HDMI 2.0 version and HDCP 2.3.
Connector & Ports
HDMI	1x HDMI
D-Sub (s)	1 x D-Sub
USB (s)	Chipset: 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 4 x USB 2.0/1.1 ports available through the internal USB headers
LAN Port (s)	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Supported Storage	CPU: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 4 x SATA 6Gb/s connectors
RAID	RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Audio	3 x audio jacks
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.2 Gen 1 header 3 x USB 2.0/1.1 headers 1 x serial port header 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper
TPM (Trusted Platform Module )	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Others
Special Features	Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Q-Flash Plus
Bundled Software	Norton Internet Security (OEM version) LAN bandwidth management software
Warranty Information
Manufacturing Warranty	3 years

Description

GIGABYTE B760M D2H mATX Motherboard

The GIGABYTE B760M D2H 14th, 13th, and 12th Gen mATX Motherboard is a cutting-edge platform that supports both 13th and 12th Gen Series Processors on Intel's LGA 1700 socket. It boasts unparalleled performance with its Hybrid 6+2+1 Phases Digital VRM Solution, ensuring efficient power delivery for optimal system stability and performance. With support for Dual Channel DDR5 and XMP Memory Modules, users can experience faster and more responsive multitasking capabilities. The 14th Gen Motherboard also features Next Generation Storage with 2 PCIe 4.0 x4 M.2 connectors, allowing for lightning-fast data transfer speeds and storage performance. Its PCIe 4.0x16 slot comes with an EZ-Latch quick-release design, making graphics card installation a breeze. The GIGABYTE B760M D2H Motherboard is equipped with a 2.5GbE LAN port, ensuring high-speed and reliable network connectivity. it provides extended connectivity options such as HDMI and D-Sub ports. To maintain an optimal temperature inside the system, Smart Fan 6 technology offers multiple temperature sensors and hybrid fan headers with FAN STOP functionality.

Special Benefits of GIGABYTE B760M D2H DDR5 mATX Motherboard

Unlock the full potential of your PC with the GIGABYTE B760M D2H DDR5 mATX motherboard. Designed for 12th, 13th, and 14th Gen Intel processors, it delivers speed, stability, and efficiency for gaming, productivity, and creative work.

Key Benefits:

DDR5 Memory Support: Experience faster data transfer speeds and improved multitasking performance.
Compact mATX Design: Fits perfectly in smaller cases without compromising on features.
Enhanced Power Delivery: Stable and reliable power for high-performance CPUs.
High-Speed Connectivity: Integrated USB 3.2 Gen 2, PCIe 4.0, and fast LAN for seamless connections.
Smart Cooling Solutions: Advanced thermal design keeps your system running efficiently under load.
Reliable Build Quality: Premium components ensure long-term durability and stability.
Future-Proof Compatibility: Ready for the latest Intel processors and next-gen expansion cards.

Boost your system’s performance today with the GIGABYTE B760M D2H DDR5 mATX motherboard – perfect for gamers, creators, and tech enthusiasts!

This motherboard is a top choice for anyone looking for performance and reliability in a compact form factor. Explore advanced features and smooth connectivity with this premium solution from the Motherboard category, powered by GIGABYTE (Intel), available now at Index IT.
