Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard

Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
-7 % In Stock
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Gigabyte B550M DS3H AM4 AMD Micro ATX Motherboard
Share:
  • Stock: In Stock
  • Brand: Gigabyte
  • Model: B550M DS3H
12,800৳
13,800৳
Ex Tax: 12,800৳

Key Features

    • AMD Ryzen 5000/4000G Series and AMD Ryzen 3rd Generation Processors
    • Dual Ultra-Fast NVMe
    • RGB FUSION 2.0 Supports
    • High-Quality Audio Capacitors
Specification
Physical Specification
Type Dual Channel DDR4 Memory Technology
Slots 4 x DIMM
Supported Memory 3rd Gen AMD Ryzen Processors:
Support for DDR4 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200 /2933 /2667 /2400 /2133 MHz
memory modules
New Generation AMD Ryzen with Radeon Graphics processors:
Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.)
/3200 /2933 /2667 /2400 /2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Max. Memory 128 GB
Basic Information
Supported CPU AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Chipset AMD B550
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm
Expansion Slots
PCI 1‎ x PCI Express x16 slot (PCIEX16), integrated into the CPU:
3rd Generation AMD Ryzen processors support PCIe 4.0 x16 mode
3rd Generation AMD Ryzen with Radeon Graphics processors support PCIe 3.0 x16 mode
1 x PCI Express x16 slot (PCIEX4), integrated into the Chipset:
Supporting PCIe 3.0 x4 mode
1 x PCI Express x1 slot (PCIEX1), integrated into the Chipset:
Supporting PCIe 3.0 x1 mode
M.2 Socket 1‎ x M.2 connector (M2A_CPU), integrated into the CPU, supporting Socket 3, M key, type
2242/2260/2280/22110 SSDs:
3rd Generation AMD Ryzen processors support SATA and PCIe 4.0 x4/x2 SSDs
3rd Generation AMD Ryzen with Radeon Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs
1 x M.2 connector (M2B_SB), integrated into the Chipset, supporting Socket 3, M key, type
2242/2260/2280 SSDs:
Supporting SATA and PCIe 3.0 x2 SSDs
Graphics
Graphics Integrated into the 3rd Generation AMD Ryzen with Radeon Graphics processors:
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Max Shared Memory 16 GB
Connector & Ports
HDMI 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
USB (s) CPU:
4 x USB 3.2 Gen 1 ports on the back panel
Chipset:
2 x USB 3.2 Gen 1 ports available through the internal USB header
6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB
header)
LAN Port (s) Realtek GbE LAN chip (1000 Mbit/100 Mbit)
Supported Storage 1‎ x M.2 connector (M2A_CPU), integrated into the CPU, supporting Socket 3, M key, type
2242/2260/2280/22110 SSDs:
3rd Generation AMD Ryzen processors support SATA and PCIe 4.0 x4/x2 SSDs
3rd Generation AMD Ryzen with Radeon Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs
1 x M.2 connector (M2B_SB), integrated into the Chipset, supporting Socket 3, M key, type
2242/2260/2280 SSDs:
Supporting SATA and PCIe 3.0 x2 SSDs
4 x SATA 6Gb/s connectors, integrated into the Chipset:
Support for RAID 0, RAID 1, and RAID 10
Audio Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
Internal I/O Ports 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x serial port header
1 x Clear CMOS jumper
1 x Q-Flash Plus button
DVI-D (s) 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
Others Information
Special Features Support for APP Center
@BIOS
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
RGB Fusion
Smart Backup
System Information Viewer
Support for Q-Flash Plus
Support for Q-Flash
Support for Xpress Install
Warranty Information
Manufacturing Warranty 03 years
Description

Gigabyte B550M DS3H Micro ATX Motherboard Price in Bangladesh

The Gigabyte B550M DS3H Micro ATX Motherboard is an excellent choice for gamers, content creators, and everyday users who want reliable performance without spending too much. Built with AMD’s B550 chipset, it supports Ryzen 3000, 4000, and 5000 series processors, making it a future-ready option for users planning performance upgrades later. Its clean layout, durable build quality, and optimized cooling design ensure a stable experience even during heavy workloads. This motherboard is perfect for users who need fast boot times, smooth multitasking, and strong connectivity. With dual M.2 slots, users can enjoy ultra-fast NVMe SSD speeds, which significantly improve real-use performance—ideal for gaming, video editing, and running large applications. The 4 DIMM slots support high-speed DDR4 RAM, allowing users to build a powerful system with excellent responsiveness. In terms of build quality, Gigabyte uses Ultra Durable components, including solid capacitors and reinforced PCIe slots that ensure long-term reliability. The motherboard’s audio section features High Definition Audio with noise guard, providing clearer and richer sound quality during gaming, movies, or meetings. For gamers, the PCIe 4.0 slot delivers better GPU performance, ensuring higher frame rates and smoother gameplay. The Micro ATX form factor makes it ideal for smaller cases, making cable management and installation easier. Whether you're building a budget gaming PC, a work-from-home setup, or a multimedia workstation, the Gigabyte B550M DS3H stands out with its balance of performance, durability, and price. The Gigabyte B550M DS3H Micro ATX Motherboard is a perfect fit for users who want strong real-world performance at a smart budget.

The benefits of AMD StoreMI:

  • Making the PC experience fast, smooth and easy
  • Optimizing computer responsiveness from system boot to application launch
  • Offering SSD performance with HDD capacity at an affordable cost
  • Quickly accessing key files by automatically learning users' computing behaviors

GIGABYTE UD series motherboards use a 5+3 phases pure digital PWM + Low RDS(on) MOSFETs design to support the 3rd Gen AMD Ryzen™ CPUs by offering incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability.

Smart Fan 5

With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM and Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly.

RGB FUSION 2.0

With B550 Motherboards, RGB Fusion 2.0 is even better with Addressable LEDs. RGB Fusion 2.0 offers users the option to control onboard RGB and external RGB / Addressable LED light strips* for their PC build. Already feature filled with colors and patterns, RGB Fusion 2.0 are now upgraded to improve the Addressable LED support. With external Addressable LED strips, where each LED is digitally addressable that users can experience even more patterns, styles, and illuminations.

Features of Gigabyte B550M DS3H Motherboard

  • Powerful AMD Ryzen Processor Support: The Gigabyte B550M DS3H supports AMD Ryzen 5000, 4000G, and 3rd Gen processors, making it ideal for gaming, multitasking, and content creation. With the LGA AM4 socket and advanced B550 chipset, users get faster performance, better stability, and long-term upgrade flexibility.
  • Dual M.2 Slots for Ultra-Fast Storage: This motherboard includes two M.2 connectors, offering PCIe 4.0 and PCIe 3.0 compatibility depending on your CPU. It supports different SSD sizes (2242 to 22110), ensuring lightning-fast boot times and storage performance—perfect for gamers and professionals using heavy applications.
  • High-Speed DDR4 Memory Support: With 4 DIMM slots supporting up to 128GB DDR4 RAM, users can run memory speeds up to DDR4-4733 (OC). This ensures exceptional multitasking, smoother workflows, and improved overall system responsiveness.
  • Next-Gen PCIe Expansion Slots: The B550M DS3H offers PCIe 4.0 x16, PCIe 3.0 x4, and PCIe 3.0 x1 slots, allowing users to install powerful graphics cards and expansion cards. Gamers benefit from improved GPU bandwidth, leading to higher FPS and better graphics performance.
  • Rich Connectivity & Display Options: Featuring HDMI and DVI-D ports, the motherboard supports 4K displays and high-resolution output. It also includes multiple USB 3.2 Gen 1 and USB 2.0 ports for seamless device connectivity along with Realtek Gigabit LAN for stable network performance.
  • Superior Build Quality & Smart Features: Powered by Gigabyte Ultra Durable components, this board offers long-lasting reliability. Extras like RGB Fusion, Q-Flash Plus, Smart Backup, and high-quality audio enhance the real-life user experience.

Gigabyte B550M DS3H price in Bangladesh

The Gigabyte B550M DS3H price in Bangladesh makes it one of the most value-packed motherboards for Ryzen users. Its offer price is 12,800৳, while the regular price is 13,800৳, giving buyers an attractive deal. This motherboard supports AMD Ryzen 3000, 4000, and 5000 series processors, delivering strong performance for gaming and productivity. With features like dual M.2 slots, high-speed DDR4 support, PCIe 4.0 compatibility, and durable build quality, the B550M DS3H is ideal for users who want reliable performance at a budget-friendly price in Bangladesh.

Why Buy Gigabyte B550M DS3H Motherboard from Index IT

Buying the Gigabyte B550M DS3H Motherboard from Index IT ensures you get a 100% genuine product with official brand warranty, giving you complete peace of mind. Index IT offers this motherboard at an affordable price in Bangladesh, making it a great choice for budget-focused users. Whether you prefer online shopping or visiting the store, Index IT provides both online and in-store availability for your convenience. With fast nationwide delivery and an easy return and replacement policy, Index IT guarantees a smooth, reliable, and customer-friendly buying experience.

Is the Gigabyte B550M DS3H compatible with Ryzen 5000 processors?

Yes, the Gigabyte B550M DS3H supports AMD Ryzen 3000, 4000, and 5000 series CPUs, ensuring excellent performance for gaming and productivity.

Does this motherboard support PCIe 4.0?

Yes, it includes PCIe 4.0 support on the primary x16 slot when paired with a compatible Ryzen CPU.

How many RAM slots are available on the B550M DS3H?

The motherboard comes with 4 DDR4 RAM slots, supporting up to 128GB of memory.

Does the Gigabyte B550M DS3H have M.2 slots?

Yes, it features dual M.2 slots, allowing users to install high-speed NVMe SSDs.

Is this motherboard good for gaming?

Absolutely. With PCIe 4.0, high-speed memory support, and strong VRM design, it delivers stable gaming performance.
