- Stock: In Stock
- Brand: GIGABYTE
- Model: B450M DS3H V2
Key Features
- Supported CPU: Ryzen 5000/ 5000 G/ 3rd/ 2nd/1st Gen Processors for Socket AM5
- Supported RAM: 4 x DDR4, up to 128GB, 3600(O.C.)Graphics Output: 1 x DVI-D port,
- 1 x HDMI port
- Features: 1 x M.2 Slot, Realtek GbE LAN
| Physical Specification | |
| Slots | 4 x DIMM |
| Supported Memory | Dual channel memory architecture Support for DDR4 3600(O.C.)/ 3466(O.C.)/ 3200(O.C.)/ 2933/ 2667/ 2400/ 2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Basic Information | |
| Supported CPU | AM4 Socket: Supports AMD Ryzen 5000 series / Ryzen 5000 G-Series/ 3rd Gen Ryzen/ 2nd Gen Ryzen/ 1st Gen Ryzen/ 2nd Gen Ryzen with Radeon Vega Graphics/ 1st Gen Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics Processors |
| Chipset | AMD B450 |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | Micro ATX Form Factor; 24.4cm x 21.5cm |
| Audio | Realtek Audio codec High Definition Audio 2/4/5.1/7.1-channel To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software. Support for S/PDIF Out |
| Type | DDR4 |
| Others | Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Fast Boot ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Support for Xpress Install |
| Expansion Slots | |
| PCI | 1 x PCI Express x16 slot, running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 1 x PCI Express x16 slot, running at x4 (PCIEX4) 1 x PCI Express x1 slot (The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.) Memory |
| Graphics | |
| Graphics | Integrated Graphics Processor: 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.2. Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies |
| Max Shared Memory | 16 GB |
| Connector & Ports | |
| HDMI | 1 x HDMI port |
| RAID | Support for RAID 0, RAID 1, and RAID 10 |
| USB (s) | Chipset: 2 x USB 3.1 Gen 1 ports available through the internal USB header 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) CPU: 4 x USB 3.1 Gen 1 ports on the back panel |
| LAN Port (s) | Realtek GbE LAN chip (10/100/1000 Mbit) |
| Supported Storage | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2* SSD support) * Actual support may vary by CPU. * Supports only M.2 SATA SSDs when using an AMD Athlon-series/ 7th Gen. A-series or Athlon X4 APU. 4 x SATA 6Gb/s connectors |
| Audio | 3 x audio jacks |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x CPU cooler LED strip/RGB LED strip header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper |
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only) |
| DVI-D (s) | 1 x DVI-D port |
| Others Information | |
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Warranty Information | |
| Manufacturing Warranty | 3 years |
Gigabyte B450M DS3H V2 AMD AM4 Motherboard Price in Bangladesh – Reliable Performance for Ryzen Builds
Building a powerful and future-ready AMD Ryzen PC starts with choosing the right motherboard, and the Gigabyte B450M DS3H V2 AMD AM4 Micro ATX Motherboard delivers an excellent balance of performance, compatibility, and value. Whether you are upgrading an existing desktop, building a budget gaming system, or creating a productivity-focused workstation, this motherboard provides the essential features needed for a stable and efficient computing experience. Designed around the AMD B450 chipset, the motherboard supports a wide range of Ryzen processors, giving users flexibility when selecting CPU options. Its Micro ATX form factor makes it an ideal choice for compact PC cases while still offering enough expansion slots and connectivity options for modern hardware. The inclusion of high-speed DDR4 memory support, M.2 SSD compatibility, and Gigabit LAN ensures that users can enjoy fast boot times, responsive performance, and reliable networking. For gamers, content creators, students, and professionals, the Gigabyte B450M DS3H V2 provides a dependable platform capable of handling daily workloads and demanding applications. If you are looking for a motherboard that combines affordability with trusted Gigabyte engineering, this model stands out as one of the most practical choices available in Bangladesh.
Why Choose the Gigabyte B450M DS3H V2 AMD AM4 Micro ATX Motherboard?
- Broad Ryzen Processor Compatibility: Supports a wide range of AMD Ryzen processors, allowing users to build systems that match their performance requirements and budget.
- Compact Micro ATX Design: The space-saving form factor makes it easier to build powerful PCs in smaller cases without sacrificing essential features.
- High-Speed DDR4 Memory Support: Enables faster multitasking, smoother application performance, and improved responsiveness for gaming and productivity tasks.
- M.2 SSD Connectivity: Supports modern NVMe storage solutions, significantly reducing boot times and accelerating file transfers.
- Reliable Power Delivery: Built with quality components that help maintain stable system operation even during demanding workloads.
- Multiple Expansion Options: PCIe slots allow users to add graphics cards, capture cards, Wi-Fi adapters, and other expansion devices as needed.
- Gigabit LAN Networking: Delivers stable and high-speed internet connectivity for online gaming, streaming, and professional work.
- Comprehensive USB Connectivity: Provides convenient connections for peripherals, external drives, keyboards, mice, and other accessories.
- Enhanced Audio Experience: Integrated HD audio technology delivers clear sound quality for entertainment, communication, and gaming.
- Excellent Value for Money: Combines essential modern features with proven reliability, making it an ideal choice for budget-conscious PC builders.
Gigabyte B450M DS3H V2 Review and Performance Analysis
The Gigabyte B450M DS3H V2 is widely regarded as a dependable motherboard for mainstream AMD Ryzen users. Its combination of B450 chipset functionality, DDR4 memory support, and M.2 storage compatibility creates a solid foundation for gaming, office productivity, content consumption, and everyday computing. The motherboard performs consistently under normal workloads while offering enough upgrade flexibility for future hardware improvements.
Its Micro ATX design is especially beneficial for users who want a compact build without compromising core functionality. With reliable networking, quality onboard audio, and Gigabyte's trusted engineering, this motherboard remains a popular choice among PC builders seeking long-term stability and cost-effective performance.
